| No. | Technical Parameter | Specification |
| 1 | Model Number | FHT228-1 |
| 2 | Overall Dimensions (L×W×H) | 1630×1500×2310mm |
| 3 | Protection Grade | IP65 (Waterproof & Dustproof) |
| 4 | Main Material | 304 Stainless Steel (Thickness: 1.5-2.0mm) |
| 5 | Access Control System | RFID Card Reader (13.56MHz), Biometric Compatible (Fingerprint/Face Recognition) |
| 6 | Working Temperature | -20℃ ~ 60℃ |
| 7 | Working Humidity | 10% ~ 90% (Non-condensing) |
| 8 | Power Supply | AC 220V ±10%, 50/60Hz |
| 9 | Power Consumption | ≤ 50W (Standby: ≤ 10W) |
| 10 | Turnstile Speed | 0.8-1.2 Seconds/Per Person |
| 11 | Anti-Tailgating Function | Infrared Sensor Detection, Anti-Tailgating Accuracy ≥ 99% |
| 12 | Weight | ≈ 180kg |
| 13 | Passage Direction | Single Direction / Bidirectional (Adjustable) |
